基本信息产品详情证书
基本信息
| 型号编号 | 浅谷湍流腌菜生产线 |
| 阿普布局方向 | 操作时落座要自左向右 |
| 最大处理速度 | 每分钟70-100米 |
| 变化线圈的工艺速度 | 每分钟50-60米 |
| 点移动速度 | 每分钟10-30米 |
| 传输方式 | 交流传动系统，通过变化调节速度 |
| 最大酸度浓度 | 200g/L氯化氢、125g/L亚铁离子、5g/L铁离子 |
| 酸中的氟含量 | 低于每百万部分少于四分之一 |
| 最低腌制时间 | 26秒 |
| 总酸槽长度：约 | 50 米 |
| 传输类型 | 灵活的 |
| 自动化生产线 | 全面的 |
| 节奏 | 流水生产线 |
| 生产范围 | 产品线 |
| 认证 | SGS一般指瑞士通用公证行。 |
| 运输包 | 按照客户要求采用塑料薄膜/胶合板箱/ |
| 规格 | 这取决于规格 |
| 商标 | 莫兰还是定制 |
| 起源 | 中国河北 |
| 商品编码 | 722100000 |
| 生产能力 | 5-10套 |
产品详情
Product Description
Preview
General introduction of
customized
Hydrochloric acid
/pickling line
This production line is push-pull Acid Pickling Unit, which adopts the most advanced Shallow Trough Turbulence Acid Pickling technology. The equipment and technology provided are reliable advanced mature whole set equipments and technology that could fulfill the buyer's need of steady production and long-term running which are proved by actual production. This technology is featured by reasonable structure, high efficiency, low consumption, convenient operation, fewer malfunctions.
Design basis
Raw MaterialCold rolled carbon structural steel, high quality carbon structural steel and low alloy steel coil
type of steel: Q195,
Q235
,ST12
,ST13,
SPCC
,SPCD20#.Hot belt temperature≤55 Degree
Centigrade
Yield strength: 210~360N/mm2Tensile strength: 270~610N/mm 2
Specification:
the thickness of steel: 2.0~~3.5mm
the width of the steel: 650~750mm
Inner diameter of coils to be pickled:
Φ610mm/Φ760mmInner diameter of coils after being pickled: ф508mm
min
Φ900mmcoil inner diameter:
max
Φ1800mm
min
Φ900mm
coil unit weight
max
13t
annual work plan:
300 days*24 hours
Energy: water, electricity and vapor
Product form: coils one after another
Production capacity:
200000tons/ Year
Process and equipments
coil loading car(1,2)
decoiler
units(1,2)
decoiling scraper(1,2)
Five roll
leveler(1,2)
crop shear1# tensioner
1#Vertical guide roller
pickling1 pickling 2
pickling 3pickling 4washing 1washing 2washing 3washing 42#
vertical guide roller
blowing machine
Hot air dryer automatic CPC2# Tensioning machine shearing machine steeringpinch roller
Coiler unit (EPC)
outlet coil unloading trolley
Our advantage:1) Customized Production
2) High cost-effective product3). All-around pre-sales &
after-sales services
4) Independent intellectual property rights
customized
Hydrochloric acid
/pickling line
This production line is push-pull Acid Pickling Unit, which adopts the most advanced Shallow Trough Turbulence Acid Pickling technology. The equipment and technology provided are reliable advanced mature whole set equipments and technology that could fulfill the buyer's need of steady production and long-term running which are proved by actual production. This technology is featured by reasonable structure, high efficiency, low consumption, convenient operation, fewer malfunctions.
Design basis
Raw MaterialCold rolled carbon structural steel, high quality carbon structural steel and low alloy steel coil
type of steel: Q195,
Q235
,ST12
,ST13,
SPCC
,SPCD20#.Hot belt temperature≤55 Degree
Centigrade
Yield strength: 210~360N/mm2Tensile strength: 270~610N/mm 2
Specification:
the thickness of steel: 2.0~~3.5mm
the width of the steel: 650~750mm
Inner diameter of coils to be pickled:
Φ610mm/Φ760mmInner diameter of coils after being pickled: ф508mm
min
Φ900mmcoil inner diameter:
max
Φ1800mm
min
Φ900mm
coil unit weight
max
13t
annual work plan:
300 days*24 hours
Energy: water, electricity and vapor
Product form: coils one after another
Production capacity:
200000tons/ Year
Process and equipments
coil loading car(1,2)
decoiler
units(1,2)
decoiling scraper(1,2)
Five roll
leveler(1,2)
crop shear1# tensioner
1#Vertical guide roller
pickling1 pickling 2
pickling 3pickling 4washing 1washing 2washing 3washing 42#
vertical guide roller
blowing machine
Hot air dryer automatic CPC2# Tensioning machine shearing machine steeringpinch roller
Coiler unit (EPC)
outlet coil unloading trolley
Our advantage:1) Customized Production
2) High cost-effective product3). All-around pre-sales &
after-sales services
4) Independent intellectual property rights
Preview
Preview
Preview
Preview
Hebei Moran provides the customers with all-around, high value-added pre- sales &
after-sales services. Factory design, selection of utility &
auxiliary facilities, unit process layout, civil foundation design reference, as well as the well-rounded training combined with theory and hands-on exercises for line operators and maintainers, all are freely available.
