Voltage sensor is used to measure the electric potential difference at
both ends of the electrical equipment or circuits.Voltage sensor divides the voltage it collects to measure
the
electrical potential difference
in DC circuit and
low-voltage, low-frequency
AC circuit.Specification
Range: -30~30V
Accuracy: ±1%
Resolution: 0.02V
Input impedance: 2MΩ
Usage
Connect Voltage Sensor to any port in SenseDisc.Connect red and black alligator clips to positive and negative poles in current sensor.Parallel connect Voltage Sensor into circuit.Voltage Sensor should be calibrated before using. Refer to calibration.Typical experiment
Series and parallel connection of resistor
Solar power generation
Measure the VA characteristic curve of small bulb
LC oscillation
Ohm's Law
Notes
Voltage sensor should be parallel
connected
to the circuit during using
Voltage sensor needs to be calibrated before using.The maximum voltage can be applied to sensor is 250V.
Integrated Design
Disc design with 7 built-in sensor modules, easy to plug, unplug and replace, offer several combinations to cater to experiment requirements.
Lightning Port Technology
Auto-locking ensures good contact at the port without lessening the ease to unplug.
Color Touchscreen, Extra Long Stand-by
1800mAh lithium battery provides a longer than 150 hours stand-by; 3.5-inch TFT 480*320 color touchscreen, 4M memory, maximum 100000 times/s sampling rate, 12-bit sampling resolution.
USB-B Port
Higher reliability than other USB ports, sound durability; Better contact ensures smooth connection to computers; Firmware upgrade via USB supported.
Easy Outdoor Collection
Outdoor collection bag provided, support off-line collection, GPS and other surroundings info are recorded for each outdoor experiment; Extra long stand-by time ensures satisfying outdoor collections.
